Part #: N23D-806956-01

The N23D-806956-01cylinder is a FAA-PMA approved replacement for Avox/Zodiac cylinder P/N 806956-01. The N23D-806956-01 PMA cylinder is manufactured to the same DOT specification as the Avox/Zodiac 806956-01 cylinder. The cylinder is constructed of a seamless aluminum liner with a carbon epoxy resin composite overwrap and polyurethane top coating. The N23D-806956-01PMA cylinder is eligible for installation into the Oxygen System on Boeing aircraft.

Part No.

N23D-806956-01​

Replaces Part No.

Avox/Zodiac
806956-01



Applies to

Boeing 747-8 SERIES

737-600
737-700
737-800
737-900
777-2002
777-3003

1 Supplement No. 13

2 Supplement No. 14

Check Supplement for detailed Eligibility list.
